Assembly services

Individual solutions – we build every battery!



If you have a specific battery requirement which is not in our range, we can produce your battery pack according to your specifications. For this, we require a sample or an exact description of the configurations.

request quote request quote

Configuration:

File

File       Volt     Cell
2 x 1 2,4   2
3 x 1 3,6 3
6 x 1 7,2 6
konfiguration_reihe

Cube

Cube       Volt       Cell
2 x 2 4,8   4
3 x 2 7,2 6
6 x 2 14,4 12
konfiguration_w%C3%BCrfel

Column

Column Volt      Cell
1 x 2 2,4   2
1 x 3 3,6 3
1 x 4 4,8 4
konfiguration_s%C3%A4ule

Column

Column     Volt         Cell
2 x 2 4,8   4
3 x 2 7,2 6
2 x 3 7,2 6
2 x 5 12,0 10
konfiguration_s%C3%A4ule2

Connection configurations for solder tags / conductor

konfiguration_l%C3%B6tfahnen_ableiter

Cable assemblies

We principally use:

  • JST 

  • Molex 

  • AMP 

  • JAE 

  • Hirose 
  • Binder 
  • Lumberg 

and other manufacturers (RoHS-compliant).
